114 Internet Settings
Select Connection options
Select Connection
drop-down list
button
Lists all settings created for LAN/Dial-up. Tap to select
the desired one.
Connection
Information area
Displays information concerning the current setting listed
in the Select Connection drop-down list button above.
This area lists the following.
For the current LAN settings
• Connection type (LAN)
• Connection media (LAN Card, USB)
• IP address (Obtain TCP/IP Information Automatically,
Specify TCP/IP Information)
• Proxy setting (No proxies, Auto configure proxies,
Set proxies)
• Mail settings (Set, None)
For Dial-up settings
• Connection type (Dial-up)
• Modem type (Card Modem, Wireless Modem, IR)
• Dial type (Tone, Pulse)
• Telephone number of ISP
• Proxy setting (No proxies, Auto configure proxies,
Set proxies)
• Mail settings (Set, None)
New button Opens a screen for creating a new connection.
Copy button Opens a screen for creating a new connection using a
duplicate of the current setting in Select Connection.
Edit button Opens a screen for editing the current setting in the
Select Connection.
Delete button Deletes the current setting in Select Connection.
Switch Connection
button
If multiple connection settings are created, tap to set the
current setting in Select Connection to the current
connection.
