Clearing Paper Jams
150
4 If the jammed page cannot be pulled
out directly, open the front cover
➊
and rotate the white knob ➋ in the
direction shown to feed the jammed
page out into the output tray.
5 After the jammed page has been
removed, push the two heater roller
release levers back up.
6 Close the front cover ➊ (if you opened
it) and then the side cover
➋.
Note: If you find that another paper jam occurs immediately after clearing a
paper jam, open the side cover and then the front cover and remove the
jammed paper as explained above. With the front cover and side cover still
open, remove the output tray and remove the printing paper from the paper
tray. Replace the output tray and close the front cover and then the side cover.
Remove the output tray once again, fan the printing paper, replace it in the
paper tray, and then replace the output tray.
2
1
2
1
