Clearing Paper Jams
147
10. Trouble-
shooting
Clearing Paper Jams
Clearing a jammed document
If the original document doesn’t feed properly during transmission or copying,
or DOCUMENT JAMMED appears in the display, first try pressing . If
the document doesn't feed out, open the auto document feeder cover and
remove it.
Important:
Do not try to remove a document without opening the auto document feeder
cover. This may damage the feeder mechanism.
1 Squeeze the cover release ➊ and open
the auto document feeder cover. Open
the document glass cover.
2 Remove the document.
x The document can be removed from either the top or the bottom slot,
whichever is easiest.
1
