P/N 11934-S23 1 of 8
Cirrus Design Section 9
SR20 Supplements
Pilot’s Operating Handbook and
FAA Approved Airplane Flight Manual
Supplement
For
Garmin GNC 420 GPS Navigator
• Note •
When a GARMIN GNC 420 GPS Navigator with VHF COM is installed
in the Cirrus Design SR20 this Supplement is applicable and must be
inserted in the Supplements Section (Section 9) of the Cirrus Design
SR20 Pilot’s Operating Handbook. This document must be carried in
the airplane at all times. Information in this supplement either adds to,
supersedes, or deletes information in the basic SR20 Pilot’s Operating
Handbook.
• Note •
This POH Supplement Revision dated Revision 02: 08-15-07
supersedes and replaces Revision 01 of this supplement
dated 05-25-05.
Serials 1005 thru 1267; This supplement supersedes GNC
420 GPS Navigator supplement, P/N 11934-S04 original
release or later.
Revision 02: 08-15-07
