3.4.14 Vertical connections

This machine is designed to be used vertical connection, but some operations under vertical connection may adversely

affect ventilation in the machine. Therefore, observe the following conditions for safe operation:

1 Installation of up to three units (Vertical connection)

The following table lists the operating temperature conditions. Use the units under conditions that keep the

outside atmosphere in this range.

Special installation (Vertical connections)

Wall

* For the securing method, see 3.4 Special installations and 3.4.2 Wall hanging.

* The same conditions apply to the working temperature requirements for a speaker system (PDP-S03-LR).

* When mounting the down converter (PDA-4003), the same working temperature conditions apply.

PC-9800 (56.4Hz)

PC-9800 (70.1Hz)

Clearance A to the wall VIDEO Machintosh (66.7Hz)

VGA (60HZ)

VGA (72.8Hz, 75Hz)

50 mm or more 0~35°C 0~35°C 0~35°C

Partition

Make sure to

mount them

so that they

will not block

any exhaust

holes.

50mm
