100

Hexagon nut with

spring washer (4 pcs.)

Attach the nut up

to the base of the

bolt as far as pos-

sible.

How to mount standard optional items (PDK-4005)

2) Assembly procedure

1. Temporarily tighten the vertical frame (1) and the horizontal frame (2) by using the M5 plus/minus screw with

washer (5) .

Before screwing together the horizontal frame and

vertical frame, place the frames on a flat surface, as

shown, and confirm that the holes match up correctly.

Table or similar flat surface

When the frames are placed on a flat surface

as above, inserting bolts into the holes is

difficult.

Caution

When assembling the PDP bracket, install an M8 nut, as shown, to keep the Special eye bolt from loosening.

(This step is not described in the instruction manual.)

Viewed from below.
