LOGOUT

Main power indicator

[CLEAR ALL] key

Press this key to redo an operation from

the beginning.

All settings will be cleared and

operation will return to the initial state.

Numeric keys

These are used to enter the number of

copies, fax numbers, and other numbers.

[LOGOUT] key ( )

When user authentication is enabled,

press this key to log out after using the

machine. When using the fax function,

this key can be pressed to send tone

signals on a pulse dial line.

[#/P] key ( )

Press this key to use a job program

when using the copier function. When

using the fax function, press this key to

dial using a program.

[BLACK & WHITE START] key

Use this key to copy or scan an original in black and

white. This key is also used to send a fax in fax mode.

Use this key to activate power save mode. The

[POWER SAVE] key blinks when the machine is in

power save mode. This key is also used to

deactivate power save mode.

[COLOUR START] key

Use this key to copy or scan an

original in colour.

This indicator lights when the

main power is switched on.

[POWER] key

Use this key to turn the

machine power on and

off.

[POWER SAVE] key

[STOP] key

Press this key to stop a copy job or scanning of

an original.

[CLEAR] key

Press this key to return

settings such as the number

of copies to "0".

mx2301_ex_qck.book 11 ページ２００９年８月７日　金曜日　午後４時６分
