REPLACING THE TONER CARTRIDGES
2-16
5
Remove the protective material from the
new toner cartridge.
6
Insert the new toner cartridge.
Align the insert holes
as shown and then
push the cartridge in.
7
Push the cartridge in until it locks securely
in place.
8
Return the cartridge lock lever.
9
Close the front cover.
After the toner cartridge
is replaced, the machine
automatically enters
resolution adjustment
mode. (In some cases,
this may take about 5
minutes.)
NOTE
A toner cartridge of a different color cannot be
installed. For instance, a yellow cartridge cannot be
installed in the cyan position.
NOTE
Do not push the white
area shown in the
illustration.
The lock lever may
come down.
CAUTION
● Do not throw the toner cartridge into a fire. Toner may fly and cause burns.
● Store toner cartridges out of the reach of small children.
