Loading Printing Paper
24
Loading Printing Paper
You can load up to 250 sheets of letter or legal paper (max. 20 lbs.) in
the paper tray. You can load up to 500 sheets of paper in the paper
cassette.
FO-4700:
The paper cassette is available as an option. To have the
cassette installed, consult your dealer.
Note:
To use A4 paper in the paper cassette, you must have a service
technician adjust the cassette.
Loading paper in the paper tray
1
Remove the received document tray.
2
If you are loading legal paper, grasp
the end of the paper tray and pull it
out.
all-FO4700.book Page 24 Friday, June 11, 1999 1:57 PM
