5-17
5
SPECIAL PAPERS
Special papers including transparency film, postcards and envelopes must be fed through the bypass tray.
1
Place the original in the document feeder
tray or on the document glass. (pages 4-6
to 4-9)
2
Load the special paper in the bypass tray.
See pages 2-6 and 2-9
for the specifications of
paper that can be used
in the bypass tray.
For the paper loading
instructions see
"Loading paper in the
bypass tray" (page 2-4).
3
Touch the [PAPER SELECT] key and then
select the bypass tray.
Select the type of paper
that you inserted in the
bypass tray.
4
Make all other desired settings such as
exposure or the number of copies, and
press the [COLOR COPY START ( )]
or [BLACK COPY START ( )] key.
If you placed the original
on the document glass,
set the output to "Sort",
you must touch the
[READ-END] key after
all pages of the original
have been scanned.
(Step 7 on page 5-8)
AUTO
EXPOSURE
UTO
ORIGINAL
AUTO 8½x11
PAPER SELECT
100
%
COPY RATIO
AIN
AL
½x8½
8½x11
NOTES
●
Output location for copies on heavy paper 2,
transparencies, and envelopes
Copies on these types of paper will be output face-
up to the tray on the left side of the machine.
They cannot be delivered to the center tray. Face-
down delivery is not possible for these papers.
●
●●
●
Color adjustment menu
As special functions of color copying, the following
color image adjustments are available. (Page 6-
11)
● RGB ADJUST
● SHARPNESS
● SUPPRESS BACKGROUND
● COLOR BALANCE
● BRIGHTNESS
● INTENSITY
WhaleII_general-copy_SEC.book 17 ページ ２００４年９月１４日 火曜日 午前１１時４５分
