6-16
IMAGE EDIT MENU
To use the following convenient copy functions, touch the [IMAGE EDIT] key in [SPECIAL MODES].
SINGLE COLOR (page 6-17)
Produces copies with a selected single color.
MIRROR IMAGE (page 6-17)
A mirror image of the original is printed.
PHOTO REPEAT (page 6-18)
Produces repeated images of a photo on a single
sheet of copy paper.
MULTI SHOT (page 6-19)
The multi shot function is used to copy up to four
originals, collectively in a specified order, per sheet
of copy paper in any one of four layout patterns.
11x17 FULL-BLEED (page 6-21)
Produces 11" x 17" (A3) full image copies onto 12"
x 18" (A3W) copy paper.
MULTI-PAGE ENLARGEMENT (page 6-22)
Enlarges an original image to a size larger than 11"
x 17" (A3) and prints divided images onto multiple
sheets of copy paper for assembly into large
composite copy.
PAMPHLET COPY (page 6-24)
The pamphlet copy function is used to arrange
copies in proper order for eventual center-stapling
and folding into a booklet. Two original pages are
copied onto each side of copy paper. Four pages
are, therefore, copied onto one sheet.
(A duplex module/2 x 500 sheet paper drawer and
a duplex bypass/inverter unit are required for this
function.)
IMAGE EDIT
OK
SINGLE COLOR PHOTO REPEAT MULTI SHOT
11x17
FULL-BLEED
PAMPHLET COPY
MIRROR
MULTI-PAGE
ENLARGEMENT
SPECIAL MODES
MARGIN SHIFT ERASE
COVERS
TRANSPARENCY
INSERTS
CENTERING
OK
DUAL PAGE
COPY
SPECIAL MODES
COLOR
ADJUSTMENTS
IMAGE EDIT
B/W
REVERSE
OK
1 Touch the key to switch to the
second SPECIAL MODES screen.
2 Touch the [IMAGE EDIT] key in the second
SPECIAL MODES screen.
