Distributed by:
AR-FR11 VERSION M.20
OPTION
Fa x/PC-Fax
OPTION
Network ScanNetwork Print
Copy
OPTION OPTION
Sharpdesk
™
AR-M620U/N
AR-M620U/N
The Centre of
Office Communications
©SHARP CORP. (MAR. 2004) H1E Printed in JapanJC620UNF
Type
Engine speed (copy/print)
Paper size
Paper weight
Paper capacity (80 g/m
2
)
Memory
First copy time*
1
Warm-up time*
2
Power requirements
Power consumption (max.)
Dimensions (W x D x H)
Weight
General
Original paper size
Continuous copy
Resolution
Gradation (scanning)
Zoom range
Preset copy ratios
Features
Max. A3 (11" x 17")
Max. 999 copies
Scan: 600 dpi Print: 600 dpi
256 levels
25 to 400% (25 to 200% using DSPF) in 1% increments
10 ratios (5R/5E) in metric system, 8 ratios (4R/4E) in
inch system
• Auto magnification/paper selection • XY zoom
• Paper type selection • Auto tray switching • Book copy
• Rotation copy • Electronic sorting • Rotation sort*
3
• Network tandem copy • Document filing
• 2-sided copy orientation change • Card shot • Margin shift
• Edge/centre erase • Copy auditing (500 accounts)
• Cover/transparency insertion • Multi shot (2-in-1/4-in-1)
• Pamphlet copy • Job build • B&W reverse*
4
• Dual page copy • Reserved copy • Tab copy
• Tab page insertion • Job programme
• Irregular original/paper size input • Mirror image
• Pre-heat/auto power shut-off modes
Copier
Facsimile*
11
Compression method
Communication protocol
Transmission time
Modem speed
Transmission resolution
Recording width
Memory
Gray scale levels
Features
MH/MR/MMR/JBIG
Super G3/G3
Less than 3 seconds*
12
33,600 bps to 2,400 bps with automatic fallback
Standard 203.2 x 97.8 dpi, up to 406.4 x 391 dpi
A3 to A5 (11" x 17" to 5
1
/
2
" x 8
1
/
2
)
Standard 2MB, expandable to 10MB
with optional 8MB flash memory
Equivalent to 256 levels
• Duplex transmission/reception
• PC-fax transmission*
13
• Quick on-line transmission
• F-Code compatibility • 999 rapid dials
• Memory transmission/reception
• Confidential communication • Timer transmission
• Broadcasting for both G3 and iFax
• Auto reduction/reception • Rotation transmission
• Long original transmission • Transmit message
• Edge/centre erase • Multi-shot • Card shot
• Transmission/reception result • Error correction mode
Resolution
Compatibility
File format
Features
Network Scanner*
5
,
†
200 x 200, 300 x 300, 400 x 400, 600 x 600 dpi
TWAIN compliant (push out method)
PDF, TIFF, TIFF-F, TIFF-FX
• Scan to e-mail/desktop (Sharpdesk™)/FTP server/HDD
• Sharpdesk™ utility (10 licenses)
• LDAP for easy e-mail address browsing and storage
• E-mail/file name entry from control panel
• Internet fax • PC-iFax transmission
Network Printer*
6
Resolution
Interface
Supported OS
Network protocols
PDL emulation
Available fonts
Features*
8
600 dpi, equivalent to 1,200 dpi (with smoothing)
IEEE 1284, USB 1.1 (Windows
®
98/98SE/Me/2000/XP only),
USB 2.0 (Windows
®
2000/XP only), 10Base-T/100Base-TX
Windows NT
®
4.0, Windows
®
95/98/Me/2000/XP, Mac OS
8.6 to 9.x, Mac OS X 10.1.5, 10.2 to 10.2.8 (not 10.2.2)*
7
TCP/IP, IPX/SPX, EtherTalk, NetBEUI
Standard: PCL 6/5e
Option: PS3*
7
80 fonts for PCL, 136 fonts for PS3*
7
• Duplex print • Pamphlet style • Binding edge
• N-up (2/4/6/8) • Paper/output tray selection
• Cover/chapter insertion • Transparency interleave
• Print with stapling • Offset output • Toner save mode
• Negative image • Mirror image • Zoom • Tab print
• Font download • Auto configuration • Watermarks
• Form overlay • Print auditor • Fit to page
• Job retention (print hold, confidential print, proof print)
• Network tandem print • Carbon copy print
• Document filing • Direct printing*
9
of PDF*
7
and TIFF files
• Barcode font compatibility*
10
• Printer administration utility & printer status monitor
†
• Network security with IP/MAC address filtering
†: For Windows environments only.
*1: When feeding A4 (8
1
/2" x 11") sheets from 1st paper tray, A4 (8
1
/2" x 11") original scanned on
document glass in Auto Exposure mode.
*2: At rated voltage, 25°C (77°F), 65% RH.
*3: Not available when equipped with a finisher.
*4: Not available in some regions.
*5: Optional AR-NS3 Network Scanner Expansion Kit required. Optional AR-P19 Printer Expansion
Kit also required for AR-M620U.
*6: For printing and network printing, AR-P19 required for AR-M620U.
*7: Optional AR-PK5 PS3 Expansion Kit required.
*8: Some features are not available according to the printer driver used.
*9: Certain PDF and TIFF files may not print out this way.
*10: Optional AR-PF1 Barcode Font Kit required.
*11: Optional AR-FX8 Fax Expansion Kit required. The AR-FX8 may not be available in some regions.
*12: Based on Sharp standard chart (A4 size, 6% coverage) at standard resolution in Super G3 mode,
33,600 bps, JBIG compression.
*13: AR-P19 also required for AR-M620U.
• Design and specifications are subject to change without prior notice.
• Windows and Windows NT are either registered trademarks or trademarks of Microsoft Corporation
in the Unites States and/or other countries. All other brand names and product names may be
trademarks or registered trademarks of their respective owners.
• The ENERGY STAR logo is a certification mark and may only be used to certify specific products that
have been determined to meet the ENERGY STAR programme requirements. ENERGY STAR is a US
registered mark. The ENERGY STAR guidlines apply to products only in the US, Europe, Australia,
New Zealand, and Japan.
AR-M620U/N
Shown with options.
2,156 mm
(84
7
/
8
")
679 mm
(26
47
/
64
")
1,192 mm
(46
59
/
64
")
SPECIFICATIONS
Console
Max. 62 cpm/ppm (A4 size or 8
1
/
2
" x 11", portrait)
Max. A3 (11" x 17"), min. A5R (5
1
/
2
" x 8
1
/
2
"R)
Paper trays 1 & 2: 60 to 105 g/m
2
Paper trays 3 (multi-purpose tray) & 4: 60 to 205 g/m
2
Multi-bypass feeder: 52 to 205 g/m
2
(single feed: 52 to 59 g/m
2
)
3,100 sheets (800 + 1,200 + 500 x 2 + 100),
max. 6,600 sheets with optional large capacity tray
128MB upgradeable to 384MB, 40GB HDD
3.9 seconds
Less than 120 seconds
Rated local AC voltage ±10%, 50/60 Hz
1.84 kW (200 to 240V), 1.80 kW (100 to 127V)
728 x 679 x 1,192 mm (28
21
/
32
" x 26
47
/
64
" x 46
15
/
16
")
Approx. 185 kg (407.3 lbs.)
U model: Digital Laser Copier/Printer
N model: Digital Multifunctional System
Print
(OPTION for U Model)
(12 pages)
(20 pages)
(82 pages)
