Turntable
Roller Stay
INSTALLATION INSTRUCTIONS
1. Remove all packing materials from the oven cavity. Check the unit for any damage, such as a misaligned
door, damaged door seals around the door or dents inside the oven cavity or on the door. If there is any
damage, please do not operate the oven until it has been checked by a SERVICE CENTRE APPROVED
BY SHARP and repaired, if necessary.
2. Accessories provided
1) Turntable 2) Roller stay
3) Operation manual and Cook book
3. Locate the roller stay in the centre of the
oven, then fit the turntable on the roller
stay. Make sure the turntable and roller
stay are centrally located and locked
together. NEVER operate the oven with-
out the roller stay and turntable.
4. The oven should not be installed in any
area where excessive heat and steam
are generated, for example, next to a
conventional oven unit.
The oven should be installed so as not
to block ventilation openings.
Allow at least 10 cm on the top, 5cm
on the both sides and at the rear of the
oven for free air space.
5. Neither the manufacturer nor the distributors can accept any liability for damage to the machine or personal
injury for failure to observe the correct electrical connecting procedure.
The A.C. voltage must be single phase 230 – 240V, 50Hz.
6. Operate the oven from a general purpose domestic outlet.
If a generator is used, do not operate the oven with non-sinusoidal outputs.
1. Door handle
2. Oven lamp
3. Door hinges
4. Door safety latches
5. See through door
6. Door seals and sealing surfaces
7. Coupling
8. Waveguide cover
9. Touch control panel
10. Digital readout
11. Ventilation openings
12. Power supply cord
OVEN DIAGRAM
