MISFEED REMOVAL

2-21

Misfeed in the stand/1 x 500 sheet paper drawer

Open the upper and lower side covers.

Push the lever upward

and gently open the

cover.

Remove the misfed paper.

Be careful not to tear the

misfed paper during

removal.

If misfed paper is not found in step 2, pull

out paper tray 1 and remove the misfed

paper.

Be careful not to tear the

misfed paper during

removal.

Gently push the paper tray into the

machine.

Push the tray firmly all the way into the machine.

Gently close the upper and lower side

covers.

After closing, confirm

that the misfeed

message has been

cleared and the normal

display appears.

Misfeed in the stand/3 x 500 sheet paper drawer

To remove a misfeed in the upper, middle, or lower tray, follow steps 1 through 5 above of "Misfeed in the stand/1

x 500 sheet paper drawer".

NOTE

Paper misfed from a paper tray may be extending out of the tray into the right side cover area. In this case if the

tray is drawn out of the machine, the paper may become torn and difficult to remove. To prevent this from

happening, always open the right side cover first and remove the misfed paper if it is extending into that area.

NOTE

If paper is loaded in the bypass tray, temporarily

remove the paper and close the bypass tray before

opening the side cover.

NOTE

The misfeed may have occurred inside the machine.

Check carefully and remove it.
