6-2
SPECIAL MODES
When the [SPECIAL MODES] key on the main screen of the copy mode is touched, the special modes screen
containing several special function touch keys will appear. These functions are shown below.
[MARGIN SHIFT] key (page 6-4)
Use this to shift the image on the copy to create
binding margins.
[ERASE] key (page 6-5)
Use this to erase peripheral shadows that occur
when making copies of books and other thick
originals.
[DUAL PAGE COPY] key (page 6-6)
This is useful to copy the left and right pages of
bound documents without shifting the document on
the document glass.
[CENTERING] key (page 6-7)
Use this to center the copied image on the paper.
[COVERS] key (page 6-9)
Use this to insert a different type of paper for use as
front and back covers. (The reversing automatic
document feeder must be used.)
[TRANSPARENCY INSERTS] key (page 6-8)
When copying onto transparencies, use this to
automatically insert a sheet of copy paper between
transparency sheets.
[OK] key on the special modes screen
Touch the [OK] key to return to the main screen of
the copy mode.
/ key
Touch these keys to switch between the special
modes menu screens.
The special modes menu consists of two screens.
Touch the key to switch to the screen below.
● The special modes below can be selected in the second screen (2/2).
[COLOR ADJUSTMENTS] key (page 6-11)
Touch this key to display the color adjustments
menu screen. This allows you to select the special
functions shown below for color adjustment when
making color copies.
[IMAGE EDIT] key (page 6-16)
Touch this key to display the image edit menu
screen. This allows you to select the special
functions shown below for image editing.
[B/W REVERSE] key (page 6-10)
A copy can be made with black and white reversed.
(This function can only be used for black and white
copying.)
SPECIAL MODES
MARGIN SHIFT ERASE
COVERS
TRANSPARENCY
INSERTS
CENTERING
OK
DUAL PAGE
COPY
ORIGINAL
SPECIAL MODES
2-SIDED COPY
OUTPUT
READY TO COPY.
AUTO
EXPOSURE
AUTO
ORIGINAL
AUTO
8½x11
PAPER SELECT
100
%
COPY RATIO
PLAIN
INTERRUPT
0
DUPLEX
SPECIAL MODES
Touch the [SPECIAL MODES]
key in the main screen
ORIGINAL
11x17
5½x8½
8½x11
8½x11
8½x11
SPECIAL MODES
COLOR
ADJUSTMENTS
IMAGE EDIT
B/W
REVERSE
OK
COLOR ADJUSTMENTS
RGB ADJUST
SUPPRESS
BACKGROUND
SHARPNESS
COLOR
BALANCE
BRIGHTNESS
INTENSITY
OK
IMAGE EDIT
OK
SINGLE COLOR
MIRROR
PHOTO REPEAT MULTI SHOT
11x17
FULL-BLEED
MULTI-PAGE
ENLARGEMENT
PAMPHLET COPY
