Using the Menu Screen

-38

The menu screens allow you to adjust the image and various projector settings.

The menu can be operated to achieve two functions, adjustment and setting.

(For adjusting the menu items, see pages 38 and 39. For setting the menu items, see pages

40 and 41.)

Menu screen (example)

ENTER button

UNDO button

MENU button

", ', \, | buttons

ENTER button

UNDO button

MENU button

", ', \, | buttons

Menu Selections

(Adjustments)

1 Press .

• The menu screen is displayed.

Note

• The “Picture” menu screen for the

selected input mode is displayed.

XV_Z200E_E_p29_43.p65 03.10.30, 13:14PM38
