-54
Changing the keycode
1 Press the buttons on the remote
control or on the projector to enter
the preset keycode in “Old Code”.
2
Press the 4 buttons on the remote
control or on the projector to enter
the new keycode in “New Code”.
3 Enter the same keycode in “Recon-
firm”.
When System Lock is set
If you have set the system lock, enter the
keycode and follow the procedure below to
release the system lock.
▼Input screen for keycode
Note
• When System Lock is set, the keycode input
screen appears after the power is turned on.
• If no keycode is entered, the image will not be
displayed, even if the projector receives the in-
put signal.
1 Press on the remote control or
on the projector to turn on the
projector.
2 When the keycode input screen ap-
pears, enter the right keycode to
start projection.
Note
•
System Lock function recognizes each button
on the remote control or on the projector as
an individual button, even if they share the
same button name. If you set the keycode with
the buttons on the projector, use only those
buttons on the projector. If you set the keycode
with the buttons on the remote control, use
only those buttons on the remote control.
Keylock Function
Use this function to lock the operation buttons on the projector.
■ Locking the Operation Buttons
Hold down
on the projector for about 3 seconds while the
projector is being turned on.
• The keylock function does not affect the operation with the re-
mote control buttons.
•
You cannot use the keylock function while the projector is warming up.
■ Taking the Keylock off
Hold down
on the projector for about 3 seconds.
• When the projector is in standby mode, you can release the
keylock by holding down
on the projector for about 3 sec-
onds.
""
""
"On-screen Display
""
""
"On-screen Display
Using the “Options1” Menu
