-74

Changing the Password

Select “Password” in the “Options (2)”

menu on the menu screen.

➝ For operating the menu screen, see

pages 42 to 45.

1 Press

" and

| to enter the

password in “Old Password”

and press

2 Press

" and

| to set the

new password and press

3 Enter the new 4-digit password

again in “Reconfirm” and

press

Note

• If you do not want to set a password, leave

the fields in procedures 2 and 3 blank and

press .

• To cancel the password settings, click

If You Forget Your

Password

If you forget the password, delete it and set a

new password using the following procedure.

Press

-74

Setting up a Password

ON ON
