Easy to Use Functions
-73
Setting up a Password
Entering the Password
Select “Password” in the “Options (2)”
menu on the menu screen.
➝ For operating the menu screen, see
pages 42 to 45.
1 Press
''
''
' or
""
""
" to select the de-
sired number and then press
||
||
|.
2 Enter the 3 remaining digits
and press
.
3 Enter the password again in
“Reconfirm” and press
.
Note
• When a password is set, you need
to enter the password to change
“PRJ Mode”, “Keylock Level”, “RS-
232C”, “Anti-Theft” and “All Reset”
settings.
A password can be set by the user to prevent adjustments to certain settings on the “Options
(2)” menu. Using a password together with the Keylock Level (page 71) is more effective.
