Sharp MX-2700G Specifications Page 99
- Page / 127
- Table of contents
- BOOKMARKS
Rated. / 5. Based on customer reviews
98
Initial Margin Shift Setting
The default setting for margin shift can be set from 0 mm
(0") to 20 mm (5/8") in increments of 1 mm (1/8").
Specify the default settings for "Side 1" (front) and "Side
2" (back) with the keys and touch the [OK] key.
(To make the number change quickly, keep your finger
on the or key.)
Erase Width Adjustment
The default setting for erase width can be set from 0 mm
(0") to 20 mm (5/8") in increments of 1 mm (1/8").
Specify the default settings for the "Edge" and "Centre"
with the keys and touch the [OK] key. (To make
the number change quickly, keep your finger on the
or key.)
Card Shot Settings
This program is used to set the default original size for
the card shot function.
Both the X (horizontal) and Y (vertical) dimensions of the
original can be set from 25 mm (1") to 210 mm (8-1/2") in
increments of 1 mm (1/8").
Select the [X] key or the [Y] key, specify the dimension
with the keys, and touch the [OK] key.
If you wish to fit the image to the paper, select the [Fit to
Page] key in the card shot settings screen and touch the
[OK] key.
Automatic Saddle Stitch
(When a saddle stitch finisher is installed.)
This is used to have saddle stitch stapling take place
automatically when the pamphlet copy function is used.
To enable this setting, select the checkbox and
touch the [OK] key.
Initial Tab Copy Setting
This is used to set the default image shift width (tab
width) for tab copying.
The default width can be set from 0 mm (0") to 20 mm
(5/8") in increments of 1 mm (1/8").
Specify the desired number with the keys and
touch the [OK] key. (To make the number change
quickly, keep your finger on the or key.)
Disabling Deletion of Job
Programs
This is used to prohibit the deletion and changing of copy
settings stored in job programs.
To enable this setting, select the checkbox and
touch the [OK] key.
Disabling of Bypass-Tray in
Duplex Copy
This is used to prohibit the use of the bypass tray when
making two-sided copies.
The bypass tray is often used to feed label sheets,
transparency film, and other special papers for which
two-sided copying is prohibited. If one of these special
papers enters the reversing unit, a misfeed or damage to
the unit may result. If special papers for which two-sided
copying is prohibited are often used, it is recommended
that you enable this setting.
To enable this setting, select the checkbox and
touch the [OK] key.
Disabling of Auto Paper Selection
This setting is used to disable the Auto Paper Selection
function.
When this setting is enabled, automatic selection of
paper that is the same size as the original on the
document glass or in the automatic document feeder
does not take place.
To enable this setting, select the checkbox and
touch the [OK] key.
System Settings
Card Shot Settings
Set the default original size for card shot.
X
86
54
OK
Y
Fit to
Page
(25 210)
mm
(25 210)
mm
