AcuLaser M4000 Series User's Guide
Printing Tasks 28
Optional paper cassette unit
The paper sizes and types supported by the optional 550-Sheet Paper Cassette Unit are the same as
the standard lower paper cassette.
The paper-loading procedure is also the same as that for the standard lower paper cassette. For
detailed information, see “MP tray and standard lower paper cassette” on page 25.
Selecting Output Tray
Face-down tray
All types and sizes of supported paper can be used. Up to 500 sheets can be stacked when using the
plain paper.
1. Pull down the paper path lever.
