Loading Printing Paper
22
Loading Printing Paper
You can load A4-size paper in the paper tray.
Maximum number of sheets:
Approx. 220 sheets (80 g/m
2
A4-size paper at room temperature)
Caution!
Do not use the blank side of paper that has already been printed on.
1 Fan the paper, and then tap the edges
against a flat surface to even the stack.
2 Pull the paper plate forward ➊. Squeeze the paper guide and
adjust it to the width of the paper
➋. Insert the stack of paper
into the tray, print side up
➌.
3 Push the paper plate back.
2
1
3
The maximum stack height
should not be higher than
the line on the paper guide
