7-17
CHAPTER7
The copier will stop when a misfeed occurs.
The message “MISFEED HAS OCCURRED. CLEAR INDICATED
AREA. PRESS FOR RECOVERY INSTRUCTIONS.” will appear with
a display of paper misfeed locations. Press the INFORMATION key for
more detailed information as necessary.
1
While holding the tray release lever, carefully slide the
large capacity tray away from the copier until it stops.
2
Remove any misfed paper from the copier and the large
capacity tray.
●
Be sure not to tear the misfed paper during removal.
●
Open and close the upper right side cover of the copier after
removing the misfed paper from the copier.
If the misfed paper cannot be removed easily, open the upper
right side cover to remove the paper.
Misfeed removal
OPTIONAL EQUIPMENT
Large capacity tray (AR-LC2)
LARGE CAPACITY TRAY (AR-LC2)
MISFEED HAS OCCURRED.
CLEAR INDICATED AREA.
PRESS FOR RECOVERY INSTRUCTIONS.
Release lever
Upper right
side cover
