7-8
CHAPTER7
20-BIN STAPLE SORTER (AR-SS2)
Manual stapling
To use the stapling feature only, without using the STAPLE SORT
mode, follow the procedure below.
1
Align the edges of the copies to be stapled.
2
Place the set of copies into the top bin, making sure the
edges are flush with the inner right corner, as shown in
the figure.
●
Make sure that there is no paper in the other sort bins. If there
is, the manual staple key will not light up.
●
Up to 30 sheets of paper can be stapled together. Exceeding this
maximum may result in damage to the stapler.
3
Press the manual staple key when it lights up.
●
The set of copies will be stapled.
OPTIONAL EQUIPMENT
20-bin staple sorter (AR-SS2)
Copies
Stapling location
