*1: The depth excludes the ADF paper chute (feeder) and stacker.
A.2 Installation Specification
Item Specification
fi-7160 fi-7260 fi-7180 fi-7280
Outer dimensions (W × D × H) (*1) 300 × 170 × 163 (mm)/
11.81 × 6.69 × 6.42 (in.)
300 × 577 × 234 (mm)/
11.81 × 22.72 × 9.21
(in.)
300 × 170 × 163 (mm)/
11.81 × 6.69 × 6.42 (in.)
300 × 577 × 234 (mm)/
11.81 × 22.72 × 9.21
(in.)
Installation space (W × D × H) (*2) 400 × 700 × 380 (mm) /
15.75 × 27.56 × 14.96
(in.)
400 × 800 × 450 (mm) /
15.75 × 31.5 × 17.72
(in.)
400 × 700 × 380 (mm) /
15.75 × 27.56 × 14.96
(in.)
400 × 800 × 450 (mm) /
15.75 × 31.5 × 17.72
(in.)
Weight 4.2 kg (9.26 lb) 8.8 kg (19.4 lb) 4.2 kg (9.26 lb) 8.8 kg (19.4 lb)
Input power Voltage range AC 100 to 240 ±10%
Phase Single phase
Frequency range 50/60 ±3 Hz
Power
consumption
Operation 38 W or less 41 W or less 42 W or less 43 W or less
Power saving 1.8 W or less
Power OFF 0.35 W or less
Ambient
condition
Temperature Operating: 5 to 35°C (41 to 95°F), Not operating: -20 to 60°C (-4 to 140°F)
Humidity Operating: 20 to 80%, Not operating: 8 to 95%
Calorific value Operation 32.7 kcal/Hr or less 35.2 kcal/Hr or less 36.1 kcal/Hr or less 37.0 kcal/Hr or less
Power saving 1.55 kcal/Hr or less
Power OFF 0.30 kcal/Hr or less
Shipping weight (*3) 6.5 kg (14.33 lb) 13.0 kg (28.66 lb) 6.5 kg (14.33 lb) 13.0 kg (28.67 lb)
