Cleaning the Flatbed (fi-7260/fi-7280)
The flatbed should be cleaned with a piece of cloth moistened
with Cleaner F1, or a sheet of Cleaning Wipe.
1 Open the document cover.
For details, refer to "1.5 Opening/Closing the Document Cover (fi-
7260/fi-7280)" (page 28).
2 Clean the following locations with a cloth moistened with
Cleaner F1 or a sheet of Cleaning Wipe.
3 Wait for the cleaned parts to dry.
4 Close the document cover.
For details, refer to "1.5 Opening/Closing the Document Cover (fi-
7260/fi-7280)" (page 28).
ATTENTION
Be careful not to let the cleaner in between the document bed and
the plastic frame.
Plastic frame
Document
bed
Document pad
