Using the Mwave DSP Telephony Features
Using the Mwave Modem
The Mwave data modem can be used with the Windows terminal
emulator to access your favorite bulletin board or online system
(PRODIGY**, CompuServe**, America Online**, or other online
systems).
Important
Before you start the communication by using your communication
program, start the Mwave modem.
OS/2
WIN
For OS/2 and Windows
To start the Mwave modem, do the following:
1
Select the following according to your operating system:
For OS/2, open the Mwave for OS/2 folder on the
OS/2 Desktop.
For Windows, open the Mwave ThinkPad window.
Note:
The screen might be different from
the actual one.
The following screen appears:
MwaveThinkPad
Recorder AudioControl
Discriminator
FAX
Country
Selection
Modem14400
Modem
Command
Reference
View
Connectors
MIDI
Select
Synthesizer
Chapter 3. Operating Your Computer 85
