Using TEL Mode
61
4. Receiving
Faxes
2 Press once.
3 Press once.
4 Enter the desired number of rings (any
number from 2 to 4).
Example: 3 rings
5 Press to return to the date and time display.
Note: If you are using Distinctive Ring, the fax machine will answer calls after two
rings regardless of the above setting.
3
STOP
Using TEL Mode
To select TEL mode, press
until the arrow in
the display points to TEL.
RESOLUTION/
RECEPTION MODE
When the reception mode is set to TEL, you must answer all calls by picking
up the fax machine’s handset or an extension phone connected to the same
line.
FAX
TEL
A.M.
TEL/FAX
The display briefly shows
your selection, then:
NUMBER OF RING
FAX REMOTE #
ENTER (2-4) (2)
RESOLUTION/
RECEPTION MODE
all.bookPage61Thursday,November15,20014:31PM
