Video Wall Projection

Info

• Before setting up the video wall projection, install Internet Explorer (version 5.0 or later).

• Video wall is not compatible with resolutions higher than SXGA.

• Image quality may deteriorate when picture signals are input through multiple projectors with an RGB

cable or an RCA cable in a daisy chain connection.

Usually, a costly image-processing device is required to set up a video wall projection.

This projector has built-in video wall capability that doesn’t require additional equipment.
