Clearing Paper Jams
133
9. Trouble-
shooting
5 Replace the drum cartridge.
• Make sure the drum cartridge is
inserted in as far as it will go.
6 Replace the toner cartridge and then
close the print compartment cover.
7 If you have a paper cassette and the
display still indicates that paper is
jammed, pull out the cassette and
remove the jammed paper.
8 Replace the paper cassette.
OR
GREEN
BLUE
GREEN
BLUE
