Sending a Fax by Automatic Dialing
53
2. Sending
Documents
X
SEARCH DIAL
1
Load the document(s).
SEND READY will appear in the
display.
• Set the resolution and/or contrast if
desired.
3
Enter the first letter of the stored
name by pressing the appropriate
letter entry key.
• If you don’t remember the first
letter, go to Step 3 (you will scroll
through the list from the
beginning).
4
Press either arrow key to scroll
through the names. Stop when the
desired name appears in the display.
• If no numbers have been stored
under the entered letter or you have
reached the end of the list, NOT
FOUND will appear.
or
Example: A
A
RESOLUTION
Q
CONTRAST
2
Press the
SEARCH DIAL
key (flip
up the Rapid Key overlay).
all-FO4700.book Page 53 Friday, June 11, 1999 1:57 PM
