AR-BC320 TROUBLESHOOTING 11 - 8

Main

code

Sub

code

Title

Finisher front alignment motor

trouble (Finisher detection)

F1 19 Display Lamp/Message

Phenomenon Detail Front alignment motor

trouble

Section Finisher

Case 1 Cause Motor lock

Check &

Remedy

Use SIM 3-3 to check the

staple motor operation.

Case 2 Cause Motor RPM abnormality

Check &

Remedy

Same as Case 1.

Case 3 Cause Over current to the motor

Check &

Remedy

Same as Case 1.

Case 4 Cause Console finisher control

PWB trouble

Check &

Remedy

Same as Case 1.

Main

code

Sub

code

Title

Finisher rear alignment motor

trouble (Finisher detection)

F1 20 Display Lamp/Message

Phenomenon Detail Rear alignment motor

trouble

Section Finisher

Case 1 Cause Motor lock

Check &

Remedy

Use SIM 3-3 to check the

staple motor operation.

Case 2 Cause Motor RPM abnormality

Check &

Remedy

Same as Case 1.

Case 3 Cause Over current to the motor

Check &

Remedy

Same as Case 1.

Case 4 Cause Console finisher control

PWB trouble

Check &

Remedy

Same as Case 1.

Main

code

Sub

code

Title

Finisher fold sensor trouble

F1 31 Display Lamp/Message

Phenomenon Detail Sensor input value

abnormality

Section Finisher

Case 1 Cause Sensor breakage

Check &

Remedy

Use SIM 3-2 to check the

sensor operation.

Case 2 Cause Harness disconnection

Check &

Remedy

Same as case 1.

Case 3 Cause Console finisher control

PWB trouble

Check &

Remedy

Same as Case 1.

Main

code

Sub

code

Title

Finisher punch unit

communication trouble

F1 32 Display Lamp/Message

Phenomenon Detail Communication error

between the console

finisher and the punch unit

Section Finisher

Case 1 Cause Improper connection or

disconnection of the

connector and the harness

of the console finisher and

the punch unit.

Check &

Remedy

Check the connector and

the harness of the

communication line.

Case 2 Cause Control PWB (PCU)

trouble

Check &

Remedy

Replace the PCU PWB.

Case 3 Cause Console finisher control

PWB trouble

Check &

Remedy

Replace the console

finisher control PWB.

Case 4 Cause Malfunction by noises

Check &

Remedy

Common Cancel

method

Can be canceled by

turning OFF/ON the power.

Main

code

Sub

code

Title

Finisher punch side registration

motor trouble

F1 33 Display Lamp/Message

Phenomenon Detail Punch side registration

motor operation trouble

Section Finisher

Case 1 Cause Motor lock

Check &

Remedy

Use SIM 3-3 to check the

staple motor operation.

Case 2 Cause Motor RPM abnormality

Check &

Remedy

Same as Case 1.

Case 3 Cause Over current to the motor

Check &

Remedy

Same as Case 1.

Case 4 Cause Console finisher control

PWB trouble

Check &

Remedy

Same as Case 1.
