AR-BC320 TROUBLESHOOTING 11 - 7

Main

code

Sub

code

Title

Finisher transport motor trouble

(Finisher detection)

F1 02 Display Lamp/Message

Phenomenon Detail Transport motor drive

trouble

Section Transport

Case 1 Cause Motor lock

Check &

Remedy

Use SIM 3-3 to check the

transport motor operation.

Case 2 Cause Motor RPM abnormality

Check &

Remedy

Same as Case 1.

Case 3 Cause Over current to the motor

Check &

Remedy

Same as Case 1.

Case 4 Cause Console finisher control

PWB trouble

Check &

Remedy

Same as Case 1.

Main

code

Sub

code

Title

Finisher paddle motor trouble

F1 03 Display Lamp/Message

Phenomenon Detail Paddle motor operation

trouble

Section Finisher

Case 1 Cause Motor lock

Check &

Remedy

Use SIM 3-3 to check the

motor operation.

Case 2 Cause Motor RPM abnormality

Check &

Remedy

Same as Case 1.

Case 3 Cause Over current to the motor

Check &

Remedy

Same as Case 1.

Case 4 Cause Console finisher control

PWB trouble

Check &

Remedy

Same as Case 1.

Main

code

Sub

code

Title

Finisher slide motor trouble

F1 06 Display Lamp/Message

Phenomenon Detail Slide motor operation

trouble

Section Finisher

Case 1 Cause Motor lock

Check &

Remedy

Use SIM 3-3 to check the

motor operation.

Case 2 Cause Motor RPM abnormality

Check &

Remedy

Same as Case 1.

Case 3 Cause Over current to the motor

Check &

Remedy

Same as Case 1.

Case 4 Cause Console finisher control

PWB trouble

Check &

Remedy

Same as Case 1.

Main

code

Sub

code

Title

Finisher staple motor trouble

(Finisher detection)

F1 10 Display Lamp/Message

Phenomenon Detail Stapling operation trouble

Section Finisher

Case 1 Cause Motor lock

Check &

Remedy

Use SIM 3-3 to check the

staple motor operation.

Case 2 Cause Motor RPM abnormality

Check &

Remedy

Same as Case 1.

Case 3 Cause Over current to the motor

Check &

Remedy

Same as Case 1.

Case 4 Cause Console finisher control

PWB trouble

Check &

Remedy

Same as Case 1.

Main

code

Sub

code

Title

Finisher bundle process motor

trouble (Finisher detection)

F1 11 Display Lamp/Message

Phenomenon Detail Bundle process motor

trouble

Section Finisher

Case 1 Cause Motor lock

Check &

Remedy

Use SIM 3-3 to check the

staple motor operation.

Case 2 Cause Motor RPM abnormality

Check &

Remedy

Same as Case 1.

Case 3 Cause Over current to the motor

Check &

Remedy

Same as Case 1.

Case 4 Cause Console finisher control

PWB trouble

Check &

Remedy

Same as Case 1.

Main

code

Sub

code

Title

Finisher tray lift motor trouble

(Finisher detection)

F1 15 Display Lamp/Message

Phenomenon Detail Lift motor trouble

Section Finisher

Case 1 Cause Motor lock

Check &

Remedy

Use SIM 3-3 to check the

staple motor operation.

Case 2 Cause Motor RPM abnormality

Check &

Remedy

Same as Case 1.

Case 3 Cause Over current to the motor

Check &

Remedy

Same as Case 1.

Case 4 Cause Console finisher control

PWB trouble

Check &

Remedy

Same as Case 1.
