5-8
Misfeed in the mail-bin stacker
If a misfeed has occurred in the mail-bin stacker during printing, remove the misfed paper following the procedure
below.
6
Remove the misfed paper.
Be careful not to tear the
misfed paper during
removal.
7
Close the paper guide.
Close the paper guide
securely.
8
Close the front cover.
1
Open the top cover.
Top cover
Move the release lever in
the direction of the arrow
in the illustration to open
the top cover.
2
Remove the misfed paper.
Be careful not to tear the
misfed paper during
removal.
After removing the paper,
press down on the top
cover to close it.
3
If the misfed paper is not found in step 2,
open the front cover.
4
Turn the roller rotating knob in the direction
of the arrow to remove the misfed paper.
5
Open the paper guide.
Unlatch the paper guide
and open it in the direction
of the arrow.
MAIL-BIN STACKER
