COPIER

TROUBLE?

MISFEED REMOVAL

Misfeed removal

Open and close the front cover to cancel the misfeed

display.

Misfeed in a paper tray

Open the side cover.

NOTE:

If the transport area misfeed indicator is lighted, clear the

transport area first. (See “Misfeed in the transport area” on the

next page.)

Remove the misfed paper.

●

Be careful not to tear the misfed paper during removal.

If the paper cannot be seen from the side, pull out the

paper tray and remove the misfed paper.

●

Be careful not to tear the misfed paper during removal.

A MISFEED HAS OCCURRED.

CLEAR INDICATED AREA.

PRESS THE KEY FOR RECOVERY

INSTRUCTIONS.
