INSTALLING THE SOFTWARE
42
Connecting a USB cable
Follow the procedure below to connect the machine to your computer.
A USB cable for connecting the machine to your computer is not included with the
machine. Please purchase the appropriate cable for your computer.
1
Insert the cable into the USB
connector on the machine.
2
Insert the other end of the cable into your computer's USB port.
• USB is available with a PC/AT compatible computer that was
originally equipped with USB and had Windows 98, Windows Me,
Windows 2000 Professional, Windows XP or Windows Vista
preinstalled.
• Do not connect the USB cable before installing the printer driver. The
USB cable should be connected during installation of the printer
driver.
• If the machine will be connected using a USB 2.0 port of your
computer, please purchase a USB cable that supports USB 2.0.
• To obtain the fastest USB 2.0 data transfer speed, "USB2.0 MODE
SWITCH" in the machine's user programs must be set to
"HI-SPEED". For more information, see "USER PROGRAMS" (p.58).
• Use the machine's "HI-SPEED" mode only when using a computer
that is running Windows 2000/XP/Vista.
• Even when the Microsoft USB 2.0 driver is used, it may not be
possible to obtain full USB 2.0 speed if a PC card supporting USB 2.0
is used. To obtain the latest driver (which may enable a higher
speed), contact the manufacturer of your PC card.
• Connection is also possible using a USB 1.1 port on your computer.
However, the specifications will be USB 1.1 specifications
(Full-Speed).
Caution
Note
!AR-208S_208D.book 42 ページ ２００７年１２月３日 月曜日 午後３時３３分
