Rated. / 5. Based on customer reviews
53
Useful Features
Picture Effect
Playback
Available modes:
Tape Playback, Card Playback
These picture effects let you play back
images with a more dramatic effect.
4 Press the DISPLAY/MODE SET
button to turn off the mode screen.
To cancel picture effect playback
Select “OFF” in step 3 above.
Notes:
• Video images in picture effect playback
mode cannot be transferred via DV cable to a
personal computer.
• You cannot use picture effect playback with
slide show playback.
Types
B/W: The picture is displayed in
black-and-white.
SEPIA: The picture is displayed in
sepia colour similar to that of an old
photograph.
SOLARI: The contrast of the subject
is enhanced, creating an unique
artistic image.
NEGA: The blacks and whites of the
image are reversed and colours of
the image are inverted.
• The example screens shown are for Tape
Playback mode.
1 During Tape Playback (or Card
Playback), press the DISPLAY/MODE
SET button until the mode screen
appears.
2 Press l or m on the Operation
button to select “PIC. EFFECT”, then
press the centre of the Operation
button.
3 Press l or m to select the desired
picture effect, then press the centre of
the Operation button.
OFF
AUD I O DUB
STRETCH PB
PIC.
F INE P I C.
EFFECT
BW
PIC. EFFECT
VL-Z800S-GB-050-056 04.1.23, 8:05 AM53
