Sharp VL-Z800S Specifications download pdf (Page 47)

37

Useful Features

Fine Picture

Available modes:

Tape Camera, Card Camera

When the subject is backlit, the image will

appear dark if it is recorded normally. The

fine picture function improves the picture by

increasing the brightness of the subject

while leaving the brighter portion of the

image unaffected. It is useful if using the

BLC function causes undesired effects

because of a great difference between the

brightness of the subject and background.

• The example screens shown are for Tape

Camera mode.

1 In Tape Camera or Card Camera

mode, press the DISPLAY/MODE

SET button until the mode screen

appears.

2 Press l or m on the Operation

button to select “FINE PIC.”, then

press the centre of the Operation

button.

EXECUTE

BLC/GAIN

SET

M

ANUAL

FOCUS

AUTO FOCUS

FINE PIC. LEVEL 1

A U T OAUTO

3 0 min3 0 min

PAUSEPAUSE

3 Press l or m to select the desired

fine picture setting then press the

centre of the Operation button.

• Each time you press l or m, the

setting changes as shown below.

“LEVEL 1” is the least bright, and

“LEVEL 3” is the brightest.

4 Press the DISPLAY/MODE SET

button to turn off the mode screen.

•“Q”, “R” or “S” appears when

on-screen indicators are turned on,

indicating that the fine picture function

is now working.

LEVEL 3

LEVEL 2

LEVEL 1

OFF

To cancel the fine picture function

Select “OFF” in step 3 above.

None

Fine picture setting On-screen indicator

Q

S

R

VL-Z800S-GB-032-038 04.1.23, 8:03 AM37
