MAC OS X

Configure the printer driver.

If you wish to use the IPP function, see "Printing using

the IPP function" (page 37) to configure the printer driver

settings.

(1) Click the [Default] icon.

If you are using Mac OS X v10.4, click the [Default

Browser] icon.

(2) Click the machine's model name.

• Using with AppleTalk:

The machine's model name usually appears as

[SCxxxxxx]*.

• Using with Bonjour:

The machine's model name usually appears as

[xxxxxx]*.

* "xxxxxx" is a sequence of characters that varies

depending on your model.

(3) Make sure that the PPD file of your

model is selected.

The PPD file of the machine is automatically selected.

(4) Click the [Add] button.

• Using with AppleTalk:

The PPD file of the machine is automatically

selected and the peripheral devices installed on

the machine are detected and automatically

configured.

• Using with Bonjour:

The "Installable Options" screen appears. Select

the machine configuration and click the

[Continue] button.

Click the [Option & Supplies] button

and click the [Driver] tab.

In Mac OS X v10.4, click the machine's name and click

the [Show Info] icon.

Select the machine configuration.

If you selected [Auto Select] in (3) of step 12, the

machine configuration is detected and automatically

configured. Check the configured settings to make sure

they are correct.

(1) Select the options that are installed on

the machine.

In Mac OS X v10.4, before you are selecting the

option, select [Installable Options].

(2) Click the [OK] button.

If you are using Mac OS X v10.4, click the [Apply

Changes] button.

(3) Click to close the window.

This completes the configuration of the printer

driver.

The PPD file is installed in the following folders on the

startup disk.

[Library] - [Printers] - [PPDs] - [Contents] -

[Resources] - [en.lproj]

(2)

(1)

(4)

(3)

You can check the options that are installed on the

machine by printing out the "All Custom Setting List".

(However, note that "Input Tray Options" must be set

to the number of trays on the machine.) To print out

the "All Custom Setting List", see the Operation

Guide.

(1)

(2)
