SPECIFICATIONS

Scanner specifications

* The resolution may be enhanced by the scanner driver depending on the scanned area and resolution.

Type Flatbed color scanner

Scanning method Document glass / SPF / RSPF

Light source Cold cathode fluorescent lamp

Resolution

Basic: 600 dpi x 600 dpi

Setting range: 50 dpi - 9600 dpi

Original types Sheet media, books

Effective scanning area 11-45/64" (297 mm) (Lengthwise) x 17" (431 mm) (Width)

Scanning speed

Color / Black and White (light source color selected): 2.88 msec/line

Grayscale / Black and White: 0.96 msec/line

Scanning colors

Black and white 2 value

Grayscale

Full Color

Protocol TWAIN / WIA (Windows XP only) / STI

Interface port

USB 1.1 port (USB-1)

USB 2.0 port (USB-2) (When the dual function board is installed.)

Drop out color Yes

Supported operating

systems

Windows 98/Windows Me

Windows 2000 Professional/Windows XP Home Edition/Windows XP Professional

(For more information, see "1. INSTALLING THE SOFTWARE (THAT

ACCOMPANIES THE MACHINE)" in the "Software setup guide".)

Void area

Top and bottom edges 7/64" (2.5 mm), right and left edges 1/8" (3.0 mm)

(at the periphery of the machine's maximum scanning area)

Interface cables

[USB cable]

Shielded twisted pair cable (max. length 10 feet (3 m))

Please purchase a commercially available USB cable. (For connection to the USB

2.0 port, the cable must support USB 2.0.)

As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification

changes for product improvement without prior notice.

Note
