Appendix
93
Setting the
Camcorder to
Factory Presettings
Available modes:
All modes
You can set the camcorder to the factory
presettings in one operation.
• The example screens shown are for Tape
Camera mode.
1 Press the DISPLAY button until the
mode screen appears.
2 Press l or m on the Operation
button to select “MENU”, then press
the centre of the Operation button.
3 Press l or m to select “EXECUTE”,
then press the centre of the Operation
button.
4 Press l or m to select Z, then
press the centre of the Operation
button.
5 Press l or m to select “DEFAULT”,
then press the centre of the Operation
button.
6 Press l or m to select “EXECUTE”,
then press the centre of the Operation
button.
OTHERS 1
BEEP
REMOTE
DEFAULT
RETURN
LANGUAGE
PHONES VOL
DEMO MODE
EXECUTE
RETURN
7 Press l or m to select “YES”, then
press the centre of the Operation
button.
• To cancel the setting, select “NO”.
8 Press the DISPLAY button to turn off
the menu screen.
Note:
• Even when you perform the steps above, the
clock and language setting maintain the
memory.
SELECT
DEFAULT
RETURN PRESE T T I NGSTO
EXCEPT CERTA IN I TEMS.
NO
YES
