LC-37DW99U

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PART

DELIVERY

DESCRIPTION

[1] LCD MODULE Assembly

1 R1LK370D3LZ20Z EC N J LCD Module Ass'y

2 QPWBM0327TPZZ AG N J CS-FPC, x2

3 CPWBX3520TPXF BR N J LCD CONTROL Unit

4 CSLDMA804WJ01 AM N J Shield Case Ass'y

5 XBPS730P06WS0 AA J Screw (for INV, LCD CONTROL), x14

6 XBBSN30P14000 AA J Screw (for Vessel), x10

7-1 CANGK3681TP02 BN N J Chassis Ass'y

7-2 CLMPCA008WJ01 N J Lamp Unit, x10

7-3 LHLDZ3254TPZZ AC N J Sheet Holder, x2

7-4 LHLDZ3382TPZZ AM N J holder, x2

7-5 LHLDZ3385TPZZ AE N J Lamp clip, x2

7-6 LHLDZ3386TPZZ AE N J Lamp clip, x2

7-7 LHLDZ3628TPZZ AE N J Lamp clip, x2

7-8 LHLDZ3629TPZZ AE N J Lamp clip, x2

7-9 POFMD0111TPZZ BR N J Polarized light reflection sheet

7-10 PREFL2367TPZZ AT N J Reflection Mirror

7-11 PSLDK2717TPZZ BC N J Diffusion Panel

7-12 PSLDK2718TPZZ AX N J Diffusion Sheet, x2

7-13 PSPAZB030WJKZ AB N J Spacer, x10

7-14 PZETE4257TPZZ AA N J Tape, x6

7-15 PZETE4258TPZZ AB N J Tape, x3

7-16 PZETKA184WJKZ AK N J Insulation Sheet

7-17 PZETKA201WJKZ AC N J Insulation Sheet, x2

7-18 RUNTKA275WJZZ BK N J INVERTER Unit A

7-19 RUNTKA276WJZZ BG N J INVERTER Unit B

7-20 TCAUZA031WJZZ AB N J Caution Label
