6. SET UP

1. Take off the belt mounted on the mast.

2. Loosen the screw of Slide Ring and

expending the LEGS.

3. Tighten the screw of Slide Ring.

4. Squeeze the TRIGGER as shown

by your hand to sliding the telescoping

LEG out. (Only Model CM-340H1,

CM-520H1have this function.)

Extending 4 LEGS until reach the

ground.

5. Model CM-340H1, CM-520H1

equipped with the LEVEL, make

sure the machine is set up in

level status.

~12~
