COM2 with Celeron Board

COM2 for peripherals

COM2 for touch function ussing a TFT adapter

If the BEETLE is delivered with TFT adapter with touch function, the jum-

per is already set ex works.

After having set the necessary settings on S1, S2 and S3 in the case of

using the touch function, continue according the following instructions.

LCD Paneltype Settings for BA7x, SNIkey 10,4"/12,1"

Paneltype 0: SVGA (800x600), set ex works.

Interrupt Paneltype reserved

S2S1

Installation Connecting the BA72A to the BEETLE/M

GB - 35
