-54

4 Clean the air filter.

• Clean the dust off the air filter and cover

with a vacuum cleaner extension hose.

5 Replace the air filter.

• Place the air filter underneath the tabs

on the filter/lamp unit cover.

6 Replace the filter/lamp unit

cover.

• Align the tab on the filter/lamp unit cover

(1) and place it while pressing the tab

(2) to close it. Then tighten the user

service screw (3) to secure the filter/

lamp unit cover.

Note

• Be sure the filter/lamp unit cover is securely

installed. The power will not turn on unless

it is correctly installed.

• If dust or dirt has collected inside the rear

and bottom air filters (not removable), clean

the filter with a vacuum cleaner extension

hose.

1

2

Tab

3

User service screw

Replacing the Air Filter
