BEFORE USING THE MACHINE

LOADING PAPER

Make sure that the machine is not copying or printing, and then follow these steps to load paper.

Loading the paper tray

Gently lift and pull out the paper tray

until it stops.

Push the pressure plate down until it

locks in place.

Push the center of the

pressure plate down until

it locks into place.

Fan the paper.

If the paper is not fanned,

double-feeds or misfeeds

may occur.

Load paper into the tray.

Gently push the paper tray into the

machine.

• Do not load paper higher than the line on

the tray (up to 250 sheets).

• Make sure that the paper fits under the tabs

on the right side of the tray.

• Make sure the stack of paper is straight

before loading it. When adding paper, take

the remaining paper out and combine it into

a single stack with the new paper.

Note

If you loaded a different size of paper than

was loaded previously in the tray, go to

"CHANGING A TRAY’S PAPER SIZE

SETTING" (p.16).

Note
