Clearing Paper Jams

10. Trouble-

shooting

1 Open the operation panel (press ➊).

2 Gently pull the jammed paper out of

the machine, making sure no torn

pieces of paper remain in the print

compartment or rollers.

3 Rotate the front gear until the film is taut, and then close the operation

panel (press down on both sides to make sure it clicks into place).

Clearing jammed printing paper

4 Flip down the green levers on each side of the white roller. Rotate the

front gear until the film is taut, and then close the operation panel (press

down on both sides to make sure it clicks into place).

all.bookPage95Tuesday,October9,20016:14PM
