Your fax has been set at the factory to print at normal contrast.

Depending on the type of paper you have loaded, you may find that

you obtain better print quality by changing the setting to LIGHT.

Press these keys:

The display will show:

FUNCTION

PRINT CONTRAST

Press 1 to select NORMAL or 2 to select LIGHT.

NORMAL LIGHT

STOP

The display will show:

PAPER SIZE SET

Press the STOP key to return to the date and time display.

Loading Printing Paper
