74
REPLACING THE TONER CARTRIDGES
Be sure to replace the toner cartridge when the message "Change the toner cartridge." appears.
The black toner cartridge can be replaced while the machine is in operation.
In copy mode
• If any one of the toner colors runs out (including black toner), color printing will not be possible. If Y, M, or C toner runs out
but Bk toner remains, black and white printing will still be possible.
• Be sure to install 5 toner cartridges (Y/M/C/Bk1/Bk2).
OK
Change the toner cartridge.
( )
Ready to scan for copy.
( Change the toner cartridge.)
Ready to scan for copy.
( Toner supply is low.)
Colors that are running low or have run out of toner are indicated in ( ).
: Yellow toner, : Magenta toner, : Cyan toner,
, : Black toner
Replace the toner cartridges of the indicated colors.
Y
M C
Bk1 Bk2
If you continue to use the machine without replacing
the cartridge, the following message will appear
when the toner runs out.
When the message appears in the message display,
replace the toner cartridge for the indicated color.
