7-33

CHAPTER7

Push the large capacity tray toward the copier and latch

it into place.

If misfed paper is not found in step 2, pull the tray out.

●

When pulling the large capacity tray out, be sure to pull it out after

the paper tray control button lamp goes out.

Remove the misfed paper.

Gently push the tray back into place.

●

Confirm that the misfeed display is cleared.

OPTIONAL EQUIPMENT

Large capacity tray (AR-LC1N)

LARGE CAPACITY TRAY (AR-LC1N)
